• Dolby� Digital
• KAM-1 Power Amplifier Circuitry
• Stereo Power (RMS): 100 Watts per Channel (Left/Right, 40Hz - 20kHz, 0.7% THD, 8 ohms)
• Universal Pre-Programmed Remote
• Video Inputs: 3 Composite
• A/B Speaker Output: Parallel
• Dolby� Pro Logic: Full Digital
• Macro Play: 3 Programmable
• Surround Power (Front Channels): 100 Watts per Channel (Left/Center/Right, 1kHz, 0.7% THD, 8 ohms)
• Speaker Connectors: Banana Plug-compatible (L/C/R Channels), One-Touch (Surround Channels)
• Surround Power (Surround Channels): 100 Watts per Channel (LSurround/RSurround, 1kHz, 0.7% THD, 8 ohms)
• Bass Management: Quick Setup
• Digital Audio Input: 2 (1 Coaxial, 1 TOS-link Optical)
• Audio Inputs/Outputs: 7 / 3
• Preouts: C/LS/RS/Sub

Amplifier Features

• A/B Speaker Output: Parallel
• KAM-1 Power Amplifier Circuitry
• Speaker Connectors: Banana Plug-compatible (L/C/R Channels), One-Touch (Surround Channels)

Audio Features

• Audio Inputs/Outputs: 7 / 3
• Auto Input Balance
• Balance Control
• Bass and Treble Controls
• Bass Management: Quick Setup
• Channel Level Control: 5.1 Channel Independent
• Crystal Semiconductor A/D and D/A Converters: 20-Bit Resolution
• Digital Audio Input: 2 (1 Coaxial, 1 TOS-link Optical)
• Digital Delay
• Dolby� 3 Stereo: Full Digital
• Dolby� Digital
• Dolby� Pro Logic: Full Digital
• Headphone Jack
• Midnight Theater Mode: 2-Stage
• Pink Noise Generator for Speaker Balancing
• Preouts: C/LS/RS/Sub
• Source Direct Listening Mode
• Variable Input Sensitivity: with Individual Source Memory
• Bass Boost
• Last Sound Mode Memory

General Features

• Auto Input Naming
• Auto Input Recognition
• AC Accessory Outlets: 2 Switched
• Audio Muting: using Remote
• Auto Function One-Touch Operation
• Direct Component Control
• Direct Input Source Selection: using Remote
• Display Dimmer
• Dynamic Rotary Encoder Volume Control
• Fluorescent Display with Volume Indication
• Macro Play: 3 Programmable
• System Control Connections for Kenwood Components: SL16/XS8 Formats
• Universal Pre-Programmed Remote

Power Ratings

• Dynamic Power (per Channel, Left and Right, 8/6/4/2 ohms): 134 Watts / - / 175 Watts
• Stereo Power: 100 Watts per Channel (Left/Right, 40Hz - 20kHz, 0.7% THD, 8 ohms)
• Surround Power (Front Channels): 100 Watts per Channel (Left/Center/Right, 1kHz, 0.7% THD, 8 ohms)
• Surround Power (Surround Channels): 100 Watts per Channel (LSurround/RSurround, 1kHz, 0.7% THD, 8 ohms)

Tuner Features

• Automatic and Manual Tuning
• Direct Access Tuning: using Remote
• Preset Call
• Quartz PLL Synthesized Digital Tuning
• Station Presets: 40 (FM/AM)

Video Features

• Video Inputs: 3 Composite
• Video Monitor Outputs: 1 Composite
• Video Outputs: 1 Composite

Please email me or my brother for questions or problems Thanks.
